OEM#: K2101New OEM Original Outright
EXPLOSION PROOF MOTOR, 5K49FN3681X, 1/3HP, 230/460V, 1200RPM, 3PH, EPFC by Marathon Motors
Your price:
$1,123.99 each
OEM#: K2101EXPLOSION PROOF MOTOR, 5K49FN3681X, 1/3HP, 230/460V, 1200RPM, 3PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$1,123.99 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, K2101, 5K49FN3681X, 1/3HP, 230/460V, 1200RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: K2101 Key Specs
Item
EXPLOSION PROOF MOTOR, 5K49FN3681X, 1/3HP, 230/460V, 1200RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
K2101
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.25
60 Hertz Rpms
1200
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Country of Origin
USA
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
2.2/1.1
Fl Efficiency
62
Frame
56
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
1/3
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
M
Model Number
5K49FN3681X
Motor Rpm 60Hz
1200
Mounting
Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1200
Rpm Range
1101-1200
Service Factor
1
Starting Type
Across the Line
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
230/460
Weight
25.8
