OEM#: J057New OEM Original Outright
CENTRIFUGAL PUMP MOTOR, 1HP, 115/208-230V, 3600RPM, 1PH, 56J FR, DP by Marathon Motors
Your price:
$457.15 each
OEM#: J057CENTRIFUGAL PUMP MOTOR, 1HP, 115/208-230V, 3600RPM, 1PH, 56J FR, DP by Marathon Motors
New OEM Original Outright
Your price:
$457.15 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Centrifugal Pump Motor, J057, 1HP, 115/208-230V, 3600RPM, 1PH, 56J FR, DP
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Technical Specs
P/N: J057 Key Specs
Item
CENTRIFUGAL PUMP MOTOR, 1HP, 115/208-230V, 3600RPM, 1PH, 56J FR, DP
OEM
Marathon Motors
OEM #
J057
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.75
60 Hertz Rpms
3600
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
12/6.2-6
Frame
56J
Horsepower
1
Insulation Class
B
Ip Code
22
Is_Motor
Yes
Kva-Code
K
Model Number
56C34D2121
Motor Rpm 60Hz
3600
Mounting
C-Face Rigid
Nema Design
Definite Duty
Opposite End Bearing
6203
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CW
Rpm
3600
Rpm Range
3001-3600
Service Factor
1.4
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
Recognized Construction and Protector
Voltage
115/208-230
Weight
23
Marathon Motors Centrifugal Pump Motor, J057, 1HP, 115/208-230V, 3600RPM, 1PH, 56J FR, DP
