OEM#: G876New OEM Original Outright
EXPLOSION PROOF MOTOR, 56C17G5327, 1HP, 115/208-230V, 1800RPM, 1PH, EPFC by Marathon Motors
Your price:
$784.16 each
OEM#: G876EXPLOSION PROOF MOTOR, 56C17G5327, 1HP, 115/208-230V, 1800RPM, 1PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$784.16 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, G876, 56C17G5327, 1HP, 115/208-230V, 1800RPM, 1PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: G876 Key Specs
Item
EXPLOSION PROOF MOTOR, 56C17G5327, 1HP, 115/208-230V, 1800RPM, 1PH, EPFC
OEM
Marathon Motors
OEM #
G876
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.75
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
13.4/6.8-6.7
Fl Efficiency
72
Frame
56C
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
1
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
J
Model Number
56C17G5327
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
N
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
115/208-230
Weight
35
