OEM#: E770New OEM Original Outright
SEVERE DUTY MOTOR, 449TTFS6530, 200HP, 460V, 1800RPM, 3PH, 447/9T FR, TEFC by Marathon Motors
Your price:
$23,888.10 each
OEM#: E770SEVERE DUTY MOTOR, 449TTFS6530, 200HP, 460V, 1800RPM, 3PH, 447/9T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$23,888.10 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, E770, 449TTFS6530, 200HP, 460V, 1800RPM, 3PH, 447/9T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Technical Specs
P/N: E770 Key Specs
Item
SEVERE DUTY MOTOR, 449TTFS6530, 200HP, 460V, 1800RPM, 3PH, 447/9T FR, TEFC
OEM
Marathon Motors
OEM #
E770
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
149
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6319
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6319
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
225
Fl Efficiency
96.5
Frame
447/9T
Hazardous Location
DIVISION 2 T2B
Horsepower
200
Insulation Class
H
Inverter Speed Range
Constant 2:1
Ip Code
54
Is_Motor
Yes
Kva-Code
G
Model Number
449TTFS6530
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6318
Opposite End Bearing Size
6318
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
460
Weight
2714
