OEM#: E625New OEM Original Outright
SEVERE DUTY MOTOR, 326TTFS6526, 50HP, 460V, 1800RPM, 3PH, 326T FR, TEFC by Marathon Motors
Your price:
$5,457.48 each
OEM#: E625SEVERE DUTY MOTOR, 326TTFS6526, 50HP, 460V, 1800RPM, 3PH, 326T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$5,457.48 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, E625, 326TTFS6526, 50HP, 460V, 1800RPM, 3PH, 326T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Technical Specs
P/N: E625 Key Specs
Item
SEVERE DUTY MOTOR, 326TTFS6526, 50HP, 460V, 1800RPM, 3PH, 326T FR, TEFC
OEM
Marathon Motors
OEM #
E625
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
37
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6312
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6312
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
60
Fl Efficiency
94.5
Frame
326T
Hazardous Location
DIVISION 2 T2B
Horsepower
50
Insulation Class
F
Inverter Speed Range
Constant 2:1
Ip Code
54
Is_Motor
Yes
Kva-Code
F
Model Number
326TTFS6526
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6311
Opposite End Bearing Size
6311
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
460
Weight
795
