OEM#: E617New OEM Original Outright
SEVERE DUTY MOTOR, 184TTFS6526, 5HP, 460V, 1800RPM, 3PH, 184T FR, TEFC by Marathon Motors
Your price:
$1,072.60 each
OEM#: E617SEVERE DUTY MOTOR, 184TTFS6526, 5HP, 460V, 1800RPM, 3PH, 184T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$1,072.60 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, E617, 184TTFS6526, 5HP, 460V, 1800RPM, 3PH, 184T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Technical Specs
P/N: E617 Key Specs
Item
SEVERE DUTY MOTOR, 184TTFS6526, 5HP, 460V, 1800RPM, 3PH, 184T FR, TEFC
OEM
Marathon Motors
OEM #
E617
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
3.7
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6206
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6206
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6.2
Fl Efficiency
90.2
Frame
184T
Hazardous Location
DIVISION 2 T2B
Horsepower
5
Insulation Class
F
Inverter Speed Range
Constant 20:1
Ip Code
54
Is_Motor
Yes
Kva-Code
J
Model Number
184TTFS6526
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6205
Opposite End Bearing Size
6205
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
460
Weight
130
Marathon Motors Severe Duty Motor, E617, 184TTFS6526, 5HP, 460V, 1800RPM, 3PH, 184T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
