OEM#: E582ANew OEM Original Outright
EXPLOSION PROOF MOTOR, 125HP, 460V, 1800RPM, 3PH, EPFC by Marathon Motors
Your price:
$31,970.12 each
OEM#: E582AEXPLOSION PROOF MOTOR, 125HP, 460V, 1800RPM, 3PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$31,970.12 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, E582A, 125HP, 460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: E582A Key Specs
Item
EXPLOSION PROOF MOTOR, 125HP, 460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
E582A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
138
50 Hertz Fl Eff
95.4
50 Hertz Hp
100
50 Hertz Kw
75
50 Hertz Rpm
1500
50 Hertz Sf
1.15
50 Hertz Voltage
380
60 Hertz Kw
93.25
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
318
Ce
N
Country of Origin
USA
Csa
N
Drive End Bearing Size
6318
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
143
Fl Efficiency
95.8
Frame
444T
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60/50
Horsepower
125
Insulation Class
F
Ip Code
54
Is_Motor
Yes
Kva-Code
G
Model Number
444TTGN16532
Motor Rpm 50Hz
1500
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6316
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
UL Listed
Voltage
460
Weight
2122
Marathon Motors Explosion Proof Motor, E582A, 125HP, 460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
