OEM#: E467ANew OEM Original Outright
SEVERE DUTY MOTOR, E467, 145TTTN6835, 2HP, 230/460V, 1800RPM, 3PH, 145T FR, TENV by Marathon Motors
Your price:
$829.40 each
OEM#: E467ASEVERE DUTY MOTOR, E467, 145TTTN6835, 2HP, 230/460V, 1800RPM, 3PH, 145T FR, TENV by Marathon Motors
New OEM Original Outright
Your price:
$829.40 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, E467, 145TTTN6835, 2HP, 230/460V, 1800RPM, 3PH, 145T FR, TENV
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Technical Specs
P/N: E467A Key Specs
Item
SEVERE DUTY MOTOR, E467, 145TTTN6835, 2HP, 230/460V, 1800RPM, 3PH, 145T FR, TENV
OEM
Marathon Motors
OEM #
E467A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
1.49
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6205
Ce
Y
Csa
Y
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
6/3
Fl Efficiency
85.5
Frame
145T
Hazardous Location
DIVISION 2 T2B
Horsepower
2
Insulation Class
F
Inverter Speed Range
Constant 10:1
Ip Code
54
Is_Motor
Yes
Kva-Code
M
Model Number
145TTTN6835
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6203
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
230/460
Weight
67
