OEM#: E448New OEM Original Outright
SEVERE DUTY MOTOR, 445TTFN6587, 150HP, 460V, 1200RPM, 3PH, 445T FR, TEFC by Marathon Motors
Your price:
$22,143.63 each
OEM#: E448SEVERE DUTY MOTOR, 445TTFN6587, 150HP, 460V, 1200RPM, 3PH, 445T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$22,143.63 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, E448, 445TTFN6587, 150HP, 460V, 1200RPM, 3PH, 445T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Technical Specs
P/N: E448 Key Specs
Item
SEVERE DUTY MOTOR, 445TTFN6587, 150HP, 460V, 1200RPM, 3PH, 445T FR, TEFC
OEM
Marathon Motors
OEM #
E448
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
112
60 Hertz Rpms
1200
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
NU318
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
NU318
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
181
Fl Efficiency
95.8
Frame
445T
Hazardous Location
DIVISION 2 T2B
Horsepower
150
Insulation Class
H
Inverter Speed Range
Constant 2:1
Ip Code
54
Is_Motor
Yes
Kva-Code
G
Model Number
445TTFN6587
Motor Rpm 60Hz
1200
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6316
Opposite End Bearing Size
6316
Orientation
Horizontal
Phase
3
Rpm
1200
Rpm Range
1101-1200
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
460
Weight
2424
Marathon Motors Severe Duty Motor, E448, 445TTFN6587, 150HP, 460V, 1200RPM, 3PH, 445T FR, TEFC
