OEM#: E2117New OEM Original Outright
PREMIUM EFFICIENCY MOTOR, 7 1/2HP, 1200RPM, 230/460V, 3PH, 254T FR, TEFC by Marathon Motors
Your price:
$2,354.46 each
OEM#: E2117PREMIUM EFFICIENCY MOTOR, 7 1/2HP, 1200RPM, 230/460V, 3PH, 254T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$2,354.46 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Premium Efficiency Motor, E2117, 7 1/2HP, 1200RPM, 230/460V, 3PH, 254T FR, TEFC
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Technical Specs
P/N: E2117 Key Specs
Item
PREMIUM EFFICIENCY MOTOR, 7 1/2HP, 1200RPM, 230/460V, 3PH, 254T FR, TEFC
OEM
Marathon Motors
OEM #
E2117
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
23/11.5
50 Hertz Fl Eff
88.5
50 Hertz Hp
7.5
50 Hertz Kw
5.6
50 Hertz Sf
1.15
Ambient Temp C
40
Approval-Ce
Yes
Bearing-Drive-End
6309
Bearing-Opp-Drive-End
6208
Catalog Number
E2117
Country of Origin
USA
Csa
Yes
Design
B
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
19.8/9.9
Fl Efficiency
91
Frame
254T
Hertz
60/50
Horsepower
7 1/2
Insulation Class
F
Ip Code
43
Is_Motor
Yes
Kva-Code
H
Model Number
254TTFL16076
Motor Rpm 50Hz
1000
Motor Rpm 60Hz
1200
Mounting
Rigid
Nameplate Rpm
1200
Phase
3
Rpm Range
1101-1200
Service Factor
1.15
Starting Type
LINE OR INVERTER
Ul
Recognized Construction
Voltage
230/460
Weight
245
Marathon Motors Premium Efficiency Motor, E2117, 7 1/2HP, 1200RPM, 230/460V, 3PH, 254T FR, TEFC
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
