OEM#: C646New OEM Original Outright
EXPLOSION PROOF MOTOR, 5KC36PNB169X, 1/4HP, 115/230V, 1800RPM, 1PH, EPNV by Marathon Motors
Your price:
$919.65 each
OEM#: C646EXPLOSION PROOF MOTOR, 5KC36PNB169X, 1/4HP, 115/230V, 1800RPM, 1PH, EPNV by Marathon Motors
New OEM Original Outright
Your price:
$919.65 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, C646, 5KC36PNB169X, 1/4HP, 115/230V, 1800RPM, 1PH, EPNV
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: C646 Key Specs
Item
EXPLOSION PROOF MOTOR, 5KC36PNB169X, 1/4HP, 115/230V, 1800RPM, 1PH, EPNV
OEM
Marathon Motors
OEM #
C646
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.19
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Ce
N
Country of Origin
USA
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Fl Amps
4.2/2.1
Fl Efficiency
59.5
Frame
48
Hazardous Location
EXP PROOF CL I GR D CL II GR F&G T3B
Hertz
60
Horsepower
1/4
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
5KC36PNB169X
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
No Design Code
Opposite End Bearing
Ball
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
115/230
Weight
24.2
Marathon Motors Explosion Proof Motor, C646, 5KC36PNB169X, 1/4HP, 115/230V, 1800RPM, 1PH, EPNV
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
