OEM#: C324BNew OEM Original Outright
EXPLOSION PROOF MOTOR, C324A, 5HP, 230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
Your price:
$1,976.49 each
OEM#: C324BEXPLOSION PROOF MOTOR, C324A, 5HP, 230/460V, 1800RPM, 3PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$1,976.49 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, C324, 184TTGS7072, 5HP, 230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: C324B Key Specs
Item
EXPLOSION PROOF MOTOR, C324A, 5HP, 230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
C324B
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
10/5
50 Hertz Fl Eff
88.5
50 Hertz Hp
3
50 Hertz Kw
2.24
50 Hertz Sf
1
50 Hertz Voltage
190/380
60 Hertz Kw
3.7
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6207
Ce
No
Country of Origin
USA
Drive End Bearing Size
6207
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
13/6.5
Fl Efficiency
87.5
Frame
184TC
Hazardous Location
EXP PROOF CL I GR D CL II GR F&G T3B
Hertz
60/50
Horsepower
5
Insulation Class
F
Ip Code
54
Is_Motor
Yes
Kva-Code
J
Model Number
184TTGN4072
Motor Rpm 50Hz
1500
Motor Rpm 60Hz
1800
Mounting
C-Face Footless
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6206
Orientation
Horizontal
Phase
3
Rpm
1800/1500
Rpm Range
1701-1800
Service Factor
1
Starting Type
Across the Line
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
230/460
Weight
161
Marathon Motors Explosion Proof Motor, C324, 184TTGS7072, 5HP, 230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
