OEM#: C1807New OEM Original Outright
EXPLOSION PROOF MOTOR, 5KC49QN0716X, 1/2HP, 110/220-230V, 1500RPM, 1PH, EPFC by Marathon Motors
Your price:
$633.29 each
OEM#: C1807EXPLOSION PROOF MOTOR, 5KC49QN0716X, 1/2HP, 110/220-230V, 1500RPM, 1PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$633.29 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, C1807, 5KC49QN0716X, 1/2HP, 110/220-230V, 1500RPM, 1PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: C1807 Key Specs
Item
EXPLOSION PROOF MOTOR, 5KC49QN0716X, 1/2HP, 110/220-230V, 1500RPM, 1PH, EPFC
OEM
Marathon Motors
OEM #
C1807
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
7.8/3.9
50 Hertz Fl Eff
0.7
50 Hertz Hp
0.5
50 Hertz Kw
0.37
50 Hertz Sf
1
50 Hertz Voltage
110/220
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Country of Origin
USA
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
7.8/3.9
Frame
56
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
50
Horsepower
1/2
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
M
Model Number
5KC49QN0716X
Motor Rpm 50Hz
1500
Mounting
Rigid
Nema Design
No Design Code
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1500
Rpm Range
1401-1500
Service Factor
1
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
110/220-230
Weight
33.2
Marathon Motors Explosion Proof Motor, C1807, 5KC49QN0716X, 1/2HP, 110/220-230V, 1500RPM, 1PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
