OEM#: 5KCR49PN3011XNew OEM Original Outright
MOTOR 3/4 1/4 HP 1725/1140 RPM 115V AUTO by Marathon Motors
Your price:
$1,000.20 each
OEM#: 5KCR49PN3011XMOTOR 3/4 1/4 HP 1725/1140 RPM 115V AUTO by Marathon Motors
New OEM Original Outright
Your price:
$1,000.20 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 5KCR49PN3011X Key Specs
Item
MOTOR 3/4 1/4 HP 1725/1140 RPM 115V AUTO
OEM
Marathon Motors
OEM #
5KCR49PN3011X
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
56
Full Load Amps
9/6.4
HP
1/4, 3/4
Hz
60
Includes
Thermal Protection
Ins. Class
B
Inverter Rated
No
Length Less Shaft
9-5/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start/Run
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Cradle Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
Auto
Nameplate RPM
1725/1140
Nominal Efficiency
70 %
Number of Speeds
2
Overall Length
11-1/2 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA (MC236833), UL (E46035)
Voltage
115
