OEM#: 326TTDBD6037New OEM Original Outright

CC PUMP MOTOR 3-PHASE 50 HP 1785 RPM by Marathon Motors

Your price:
$5,458.27 eachReady to ship
HomeMarathon Motors326ttdbd6037
CC PUMP MOTOR 3-PHASE 50 HP 1785 RPM by Marathon Motors
CC PUMP MOTOR 3-PHASE 50 HP 1785 RPM by Marathon Motors

OEM#: 326TTDBD6037
CC PUMP MOTOR 3-PHASE 50 HP 1785 RPM by Marathon Motors

New OEM Original Outright
Your price:
$5,458.27 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 326TTDBD6037 Key Specs
Item
CC PUMP MOTOR 3-PHASE 50 HP 1785 RPM
OEM
Marathon Motors
OEM #
326TTDBD6037
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC003A
Country of Origin
Mexico
Duty
Continuous
Frame
326JP
Full Load Amps
118/59
HP
50
Hz
60/50
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
24-7/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
Pump
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Cast Iron
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
JP Threaded
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Close-Coupled Pump
Motor Thermal Protection
None
Nameplate RPM
1785
Nominal Efficiency
96.2%
Overall Length
33 in
Phase
3
Shaft Diameter
1-1/4 in
Shaft Length
24-7/8 in
Standards
CE, CSA Certified (LR2025), UL Recognized (E49747)
Voltage
230/460
