OEM#: 184THFCD9026New OEM Original Outright
IEEE 841 MOTOR 3-PH TEFC 5 HP T2B by Marathon Motors
Your price:
$1,857.77 each
OEM#: 184THFCD9026IEEE 841 MOTOR 3-PH TEFC 5 HP T2B by Marathon Motors
New OEM Original Outright
Your price:
$1,857.77 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 184THFCD9026 Key Specs
Item
IEEE 841 MOTOR 3-PH TEFC 5 HP T2B
OEM
Marathon Motors
OEM #
184THFCD9026
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC003A
Country of Origin
Mexico
Duty
Continuous
Frame
184T
Full Load Amps
6.2
HP
5 hp
Hz
60
Includes
Breather/Drain
Ins. Class
F
Length Less Shaft
13-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
IEEE Motor
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1755
Nominal Efficiency
90.2 %
Number of Speeds
1
Overall Length
16-3/16 in
Phase
3
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
1-1/8 in
Shaft Length
2-3/4 in
Standards
CE, CSA (LR2025), UL (E49747)
Voltage
460
