OEM#: 145TTFR16033New OEM Original Outright
MOTOR 3-PH 1.5 HP 1750 RPM 230/460V by Marathon Motors
Your price:
$984.66 each
OEM#: 145TTFR16033MOTOR 3-PH 1.5 HP 1750 RPM 230/460V by Marathon Motors
New OEM Original Outright
Your price:
$984.66 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 145TTFR16033 Key Specs
Item
MOTOR 3-PH 1.5 HP 1750 RPM 230/460V
OEM
Marathon Motors
OEM #
145TTFR16033
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
UL (E49747), CSA (LR2025), CE
CC Number
CC003A
Country of Origin
USA
Duty
Continuous
Frame
145T
Full Load Amps
4.6-4.8/2.4
Horsepower
1-1/2
Hz
60/50
Insulation Class
F
Inverter Rated
Yes
Length Less Shaft
11-3/8 in
Maximum Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1750
Nominal Efficiency
86.5 %
Number of Speeds
1
Overall Length
13-3/4 in
Phase
3
Shaft Diameter
7/8 in
Shaft Length
2-3/8 in
Voltage
230/460
