OEM#: 143TTDR6027New OEM Original Outright
MOTOR 3-PH 1 HP 1760 RPM 230/460V by Marathon Motors
Your price:
$688.50 each
OEM#: 143TTDR6027MOTOR 3-PH 1 HP 1760 RPM 230/460V by Marathon Motors
New OEM Original Outright
Your price:
$688.50 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 143TTDR6027 Key Specs
Item
MOTOR 3-PH 1 HP 1760 RPM 230/460V
OEM
Marathon Motors
OEM #
143TTDR6027
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC003A
Country of Origin
USA
Duty
Continuous
Frame
143T
Full Load Amps
3.2-3.2/1.6
HP
1
Hz
60/50
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
9-3/4 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
T-Stat
Nameplate RPM
1760
Nominal Efficiency
85.5 %
Number of Speeds
1
Overall Length
12-1/8 in
Phase
3
Shaft Diameter
7/8 in
Shaft Length
2-3/8 in
Standards
UL (E49747), CSA (LR2025), CE
Voltage
230/460
