OEM#: 056T17G15551New OEM Original Outright
HAZARDOUS LOC MTR 3 PH TEFC 3/4 HP T3B by Marathon Motors
Your price:
$735.04 each
OEM#: 056T17G15551HAZARDOUS LOC MTR 3 PH TEFC 3/4 HP T3B by Marathon Motors
New OEM Original Outright
Your price:
$735.04 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 056T17G15551 Key Specs
Item
HAZARDOUS LOC MTR 3 PH TEFC 3/4 HP T3B
OEM
Marathon Motors
OEM #
056T17G15551
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
56
Full Load Amps
3/1.5
HP
3/4
Hazardous Location Class
1 C,D / 2 E,F,G
Hz
60/50
Includes
12-5/64 in
Ins. Class
B
Lead Length
6 in
Length Less Shaft
12-5/64 in
Max Ambient Temperature
40 Degrees C
Motor Application
Hazardous Location
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Type
Rigid Base
Motor Service Factor
1
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
Auto
NEMA Design
B
Nameplate RPM
1725
Nominal Efficiency
86.5%
Overall Length
12-5/64 in
Phase
3
Shaft Diameter
12-5/64 in
Shaft Length
12-5/64 in
Standards
CSA Certified (LR47504), UL Listed (E12044)
Temperature Code
T3B
Voltage
230/460
