OEM#: 056C17D2101New OEM Original Outright
DDB MOTOR 1/3 HP 1725 RPM 1-PH DRIPPROOF by Marathon Motors
Your price:
$485.72 each
OEM#: 056C17D2101DDB MOTOR 1/3 HP 1725 RPM 1-PH DRIPPROOF by Marathon Motors
New OEM Original Outright
Your price:
$485.72 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 056C17D2101 Key Specs
Item
DDB MOTOR 1/3 HP 1725 RPM 1-PH DRIPPROOF
OEM
Marathon Motors
OEM #
056C17D2101
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Commercial Laundry Dryer
Body Diameter
5-5/8 in
Capacitor Required
Included
Country of Origin
Mexico
Duty
Continuous
Frame
56Z
Full Load Amps
5.8/2.8-2.9
HP
1/3
Hz
60
Ins. Class
B
Length Less Shaft
8-1/2 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Dripproof
Motor Mounting Position
Horizontal
Motor Mounting Type
Resilient Base
Motor Service Factor
1.35
Motor Shaft Design
Threaded
Motor Shaft Rotation
CCWSE
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1725
Nominal Efficiency
52 %
Number of Speeds
1
Overall Length
14-1/16 in
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
8-7/16 in
Shaft Diameter
5/8 in
Shaft Length
5-11/16 in
Standards
CSA Certified (LR2025), UL Recognized (E6312)
Voltage
115/208-230
