OEM#: 056B17D11037New OEM Original Outright
GENERAL PURPOSE MOTOR 1/3 HP 115/230V by Marathon Motors
Your price:
$449.24 each
OEM#: 056B17D11037GENERAL PURPOSE MOTOR 1/3 HP 115/230V by Marathon Motors
New OEM Original Outright
Your price:
$449.24 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 056B17D11037 Key Specs
Item
GENERAL PURPOSE MOTOR 1/3 HP 115/230V
OEM
Marathon Motors
OEM #
056B17D11037
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
56
Full Load Amps
3.8/1.9
HP
1/3
Hz
60/50
Ins. Class
B
Inverter Rated
No
Length Less Shaft
9-1/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start/Run
Motor Efficiency Group
Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.35
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
Manual
Nameplate RPM
1725
Nominal Efficiency
72.4 %
Number of Speeds
1
Overall Length
11 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CE, CSA (LR2025), UL (E49747)
Voltage
115/230
