OEM#: 048S17D2090New OEM Original Outright

SP MOTOR SPLIT-PH 1/3 HP 60 HZ by Marathon Motors

Your price:
$225.50 eachReady to ship
HomeMarathon Motors048S17D2090
SP MOTOR SPLIT-PH 1/3 HP 60 HZ by Marathon Motors
SP MOTOR SPLIT-PH 1/3 HP 60 HZ by Marathon Motors

OEM#: 048S17D2090
SP MOTOR SPLIT-PH 1/3 HP 60 HZ by Marathon Motors

New OEM Original Outright
Your price:
$225.50 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 048S17D2090 Key Specs
Item
SP MOTOR SPLIT-PH 1/3 HP 60 HZ
OEM
Marathon Motors
OEM #
048S17D2090
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
48
Full Load Amps
6.6
HP
1/3 hp
Hz
60
Ins. Class
B
Length Less Shaft
7-3/4 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Type
Rigid Base
Motor Service Factor
1
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
86.5 %
Number of Speeds
1
Phase
1
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
1/2 in
Shaft Length
1-9/16 in
Standards
CSA (LR2025), UL (E49747)
Voltage
115
