OEM#: 48-1607New OEM Original Outright

DUAL ENERGY COMPENSATED GM DETECTORS by Ludlum Measurements

Your price:
$2,702.84 eachReady to ship
HomeLudlum Measurements481607
DUAL ENERGY COMPENSATED GM DETECTORS by Ludlum Measurements
DUAL ENERGY COMPENSATED GM DETECTORS by Ludlum Measurements
DUAL ENERGY COMPENSATED GM DETECTORS by Ludlum Measurements
DUAL ENERGY COMPENSATED GM DETECTORS by Ludlum Measurements

OEM#: 48-1607
DUAL ENERGY COMPENSATED GM DETECTORS by Ludlum Measurements

New OEM Original Outright
Your price:
$2,702.84 each

Counter, 3.5in Width, 7.5in Height, 8.5in Length

Ready to ship
Asset Information

Shipment restricted to US and Canada

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

The Model 5 is a gamma exposure ratemeter equipped with two internally housed, energy-compensated GM detectors that measure over the range of 0 to 20 mSv/h (0 to 2000 mR/hr). The cast aluminum instrument housing with its separate battery compartment and accompanying metal handle offer an industrial robustness and quality that promote long lasting protection and instrument life. The front-panel controls include a rotary switch for selecting the five display ranges and instrument shut-off, an audio on/off switch, a fast/slow response switch, and push-buttons for count reset and battery test. The Model 5 is a complete turn-key system and includes two inDin cell batteries.

  • Range: 0 to 20 mSv/h (0 to 2000 mR/hr)
  • Energy Compensated GM Detectors
  • Rugged
  • 5-Range Analog Ratemeter
Features
  • Range: 0 to 20 mSv/h (0 to 2000 mR/hr)
  • Energy Compensated GM Detectors
  • Rugged
  • 5-Range Analog Ratemeter
Technical Specs
P/N: 48-1607 Key Specs
Item
DUAL ENERGY COMPENSATED GM DETECTORS
OEM
Ludlum Measurements
OEM #
48-1607
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Alert / Alarm
No
Audio
Built-in unimorph type speaker with ON/OFF switch
Backlight
No
Battery Life
Typically greater than 2000 hours
Calibration Controls
Accessible from the front of the instrument
Detector
2 energy-compensated GMs; housed inside instrument enclosure
Dimensions
19.0 cm H x 8.9 cm W x 21.6 cm L
Energy Response
Within 15% of true value from 60 keV to 3 MeV
High Voltage
540 ± 25 VDC
Indicated Use
Radiography Survey; Gamma Survey
Length
8.5in
Meter
Analog dial: 0 to 2 mR/hr; BAT TEST (others available)
Multiplier
x0.1; x1; x10; x100; x1000
Overload Protection
Yes
Package Quantity
1
Power
Two each "D" cell batteries (housed in sealed compartment that is externally accessible)
RS-232 Port
No
Range
0 to 2 R/hr
Reset
Pushbutton to zero meter
Temperature Range
-20 to 50 deg C
Weight
1.6 kg
Working Environment
Normal working conditions
Fitments

The Model 5 is a gamma exposure ratemeter equipped with two internally housed, energy-compensated GM detectors that measure over the range of 0 to 20 mSv/h (0 to 2000 mR/hr). The cast aluminum instrument housing with its separate battery compartment and accompanying metal handle offer an industrial robustness and quality that promote long lasting protection and instrument life. The front-panel controls include a rotary switch for selecting the five display ranges and instrument shut-off, an audio on/off switch, a fast/slow response switch, and push-buttons for count reset and battery test. The Model 5 is a complete turn-key system and includes two inDin cell batteries.

  • Range: 0 to 20 mSv/h (0 to 2000 mR/hr)
  • Energy Compensated GM Detectors
  • Rugged
  • 5-Range Analog Ratemeter
    • Ludlum Measurements
      • MODEL 5
