6.6FT USB 2.0 A MALE - B MALE CABLE - BLACK by Legrand AV (C2G)
OEM#: 281026.6FT USB 2.0 A MALE - B MALE CABLE - BLACK by Legrand AV (C2G)
Just plug-and-play for keyboards, mice, modems, printers, and other USB peripherals. This cable provides a transfer rate up to 480 Mbps depending upon the peripheral's USB version, and easily attaches to any USB device. Foil and braid shielding reduces EMI/RFI interference and twisted pair construction helps reduce crosstalk thus ensuring high speed, error-free data transfer.
- Use to connect a printer or camera to a PC
- Prefect replacement cable or extra cable for longer length
- Download a PDF with the technical specifications of this product on the Support tab
- PC and Mac compatible
- Supports high speed USB 2.0 devices (480 Mbps), and is backwards compliant with full-speed USB 1.1 (12 Mbps) and low speed USB 1.0 (1.5 Mbps)
- Nominal Impedance with Tolerance - 90?±15%
- Nominal Capacitance - 131PF/M
- Nominal Velocity of Propagation - 12Mb/s
- DC Resistance - 28AWG 239Ohm/Km @20°C, 24AWG 94.2Ohm/Km @20°C
- Insulation Resistance - 10M?
Conductor 1 (x2)
- Material - Stranded Tinned Copper
- Size - 28AWG (7/0.127 TC)
- Insulation - HD-PE
- OD - 0.85mm
- Color - White/Green (twisted pair)
Conductor 2 (x2)
- Material - Stranded Tinned Copper
- Size - 24AWG (7/0.20 TC)
- Insulation - SR-PVC
- OD - 1.1mm
- Color - Red, Black
Drain Wire
- Material - Tinned Copper
- Size - 28AWG (7/0.12 TC)
Shield 1
- Material - Aluminum Mylar Wrap
Shield 2
- Material - Braided Copper
- Coverage - 65%
Jacket
- Material - PVC
- OD - 4.7mm
USB 2.0 A and B Connector
- Gender - Male
- Insulation - White PBT
- Contact Material - Gold Flash
- Shell Material - Nickel Plated
Just plug-and-play for keyboards, mice, modems, printers, and other USB peripherals. This cable provides a transfer rate up to 480 Mbps depending upon the peripheral's USB version, and easily attaches to any USB device. Foil and braid shielding reduces EMI/RFI interference and twisted pair construction helps reduce crosstalk thus ensuring high speed, error-free data transfer.
