OEM#: M1125265.00New OEM Original Outright
PARALLEL SHAFT GEARMOTORS 90V by Leeson
Your price:
$1,151.29 each
OEM#: M1125265.00PARALLEL SHAFT GEARMOTORS 90V by Leeson
New OEM Original Outright
Your price:
$1,151.29 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Leeson M1125265.00, 1/8 HP, 167 RPM, 90VDC, TENV, P300, 11:1 Ratio, 43 In-Lbs
DC permanent magnet gearmotors rated for continuous duty. Designed for use with fullwave non-filtered SCR controls or battery supplied low voltage or adjustable speed applications requiring constant torque throughout the speed range.
DC permanent magnet gearmotors rated for continuous duty. Designed for use with fullwave non-filtered SCR controls or battery supplied low voltage or adjustable speed applications requiring constant torque throughout the speed range.
Technical Specs
P/N: M1125265.00 Key Specs
Item
PARALLEL SHAFT GEARMOTORS 90V
OEM
Leeson
OEM #
M1125265.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Country of Origin
USA
Csa
Yes
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
1.6
Frame Material
Steel
Gear Motor Rpm
167
Gearhead / Shaft Type
Parallel
Horsepower
1/8
Hp Range
1/11 to 1/8
Insulation Class
F
Is_Motor
Yes
Model
CM31D17VZ9
Output Torque (In-Lbs)
43
Overhung Load (Lbs.)
197
Ratio To 1
11
Rotation
Reversible
Rpm Range
0-1000
Series
P300
Service Factor
1
Type & Frame Style
P302-31
Ul
Yes
Voltage
90
Weight Lbs
16
Leeson M1125265.00, 1/8 HP, 167 RPM, 90VDC, TENV, P300, 11:1 Ratio, 43 In-Lbs
DC permanent magnet gearmotors rated for continuous duty. Designed for use with fullwave non-filtered SCR controls or battery supplied low voltage or adjustable speed applications requiring constant torque throughout the speed range.
DC permanent magnet gearmotors rated for continuous duty. Designed for use with fullwave non-filtered SCR controls or battery supplied low voltage or adjustable speed applications requiring constant torque throughout the speed range.
