OEM#: M1125277.00New OEM Original Outright

1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 RATIO, 135 IN-LBS by Leeson

Your price:
$1,213.40 eachReady to ship
HomeLeesonM112527700
1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 RATIO, 135 IN-LBS by Leeson
1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 RATIO, 135 IN-LBS by Leeson

OEM#: M1125277.00
1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 RATIO, 135 IN-LBS by Leeson

New OEM Original Outright
Your price:
$1,213.40 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Leeson M1125277.00, 1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 Ratio, 135 In-Lbs

DC Gearmotor with Right-Angle Shaft. 1/4HP, 62 RPM, Gear Ratio 40 to 1, Overhung Load 235 Pounds, 135 Lb. In. Full Load Torque, Totally-Enclosed Non-Ventilated (TENV) Enclosure, 32 Frame, 90V, Name Plate Amps 3.7.




Technical Specs
P/N: M1125277.00 Key Specs
Item
1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 RATIO, 135 IN-LBS
OEM
Leeson
OEM #
M1125277.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Country of Origin
USA
Csa
Yes
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
3.7
Frame Material
Steel
Gear Motor Rpm
62
Gearhead / Shaft Type
Right-Angle
Horsepower
1/4
Hp Range
1/4
Insulation Class
F
Is_Motor
Yes
Model
CM32D25VZ6
Output Torque (In-Lbs)
135
Overhung Load (Lbs.)
235
Ratio To 1
40
Rotation
Reversible
Rpm Range
0-1000
Series
13
Service Factor
1
Type & Frame Style
13F40-32
Ul
Yes
Voltage
90
Weight Lbs
17

Leeson M1125277.00, 1/4 HP, 62 RPM, 90VDC, TENV, 13, 40:1 Ratio, 135 In-Lbs

DC Gearmotor with Right-Angle Shaft. 1/4HP, 62 RPM, Gear Ratio 40 to 1, Overhung Load 235 Pounds, 135 Lb. In. Full Load Torque, Totally-Enclosed Non-Ventilated (TENV) Enclosure, 32 Frame, 90V, Name Plate Amps 3.7.
