OEM#: 191491.00New OEM Original Outright
MOTOR 2 HP 1750 145TC 208-230/460V by Leeson
Your price:
$2,401.89 each
OEM#: 191491.00MOTOR 2 HP 1750 145TC 208-230/460V by Leeson
New OEM Original Outright
Your price:
$2,401.89 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 191491.00 Key Specs
Item
MOTOR 2 HP 1750 145TC 208-230/460V
OEM
Leeson
OEM #
191491.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC005A
Country of Origin
China
Frame
145TC
Full Load Amps
5.4/2.7
Green Certification or Other Recognition
NEMA Premium(R) Rated
HP
2
Hz
60/50
Ins. Class
F
Length Less Shaft
11-5/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
Washdown
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Stainless Steel
Motor Mounting Type
Face/Base
Motor Service Factor
1.15
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1750
Nominal Efficiency
86.5 %
Phase
3
RPM Range
1701-1800
Shaft Diameter
7/8 in
Shaft Length
2 in
Voltage
230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
