OEM#: 191207.00New OEM Original Outright

WASHDOWN MOTOR-.75/.5HP, 208-230/460V, 1740/1440RPM, TENV, RIGID C by Leeson

Your price:
$2,219.13 eachReady to ship
HomeLeeson19120700
WASHDOWN MOTOR-.75/.5HP, 208-230/460V, 1740/1440RPM, TENV, RIGID C by Leeson
WASHDOWN MOTOR-.75/.5HP, 208-230/460V, 1740/1440RPM, TENV, RIGID C by Leeson

OEM#: 191207.00
WASHDOWN MOTOR-.75/.5HP, 208-230/460V, 1740/1440RPM, TENV, RIGID C by Leeson

New OEM Original Outright
Your price:
$2,219.13 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Washguard SST All-Stainless Washdown Motors, 3-Phase: .75/.5HP, 1740/1440 RPM, Totally-Enclosed Non-Ventilated (TENV) Enclosure, 56 Frame, RIGID C, 208-230/460V, 3PH, 60/50HZ, Name Plate Amps 2.4-2.3/1.15&2/1, Continuous duty, 1.15 Service Factor, No thermal protection, Ambient 40 C, Reverse Rotation, Shaft Length: 1-7/8, Shaft Diameter: 5/8.

Stainless Steel Tough for demanding washdown applications

  • All exterior components of 300 series stainless steel, including motor frame, endshield and conduit box castings
  • Moisture resistant sealant between frame and endbells
  • Full-fact nameplate is laser-etched on the motor frame
  • Built to withstand the demanding washdown environments found in the food processing, chemical processing and beverage industries
  • No paint or coatings of any type are used on the exterior of the motor
  • Four locations for T-drains provided on each endshield
  • Meets IP55 enclosure protection
  • Three phase motors are suitable for use on VFDs
  • 10:1 ratio for constant or variable torque at 1.0 SF


Technical Specs
P/N: 191207.00 Key Specs
Item
WASHDOWN MOTOR-.75/.5HP, 208-230/460V, 1740/1440RPM, TENV, RIGID C
OEM
Leeson
OEM #
191207.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6205
Catalog Number
191207.00
Compatible With/Replaces
Baldor CSWDM3542, WEG .7518EP3ESS56C, Marathon N412
Construction
Stainless Steel
Country of Origin
China
Csa
Y
Design
Sq Cage Inductor Run
Duty
Continuous
Efficiency Type
Standard
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
2.4-2.3/1.15
Frame
56C
Hertz
60/50
Horsepower
3/4
Is_Motor
Yes
Motor Rpm 60Hz
1740
Mounting
C-Face Rigid
Nameplate Amps
2.4-2.3/1.15&2/1
Phase
3
Rotation
CCW/CW
Rpm
1740
Rpm Range
1701-1800
Service Factor
1.15
Shaft Diameter
5/8
Shaft Length (in)
1-7/8
Thermal Protection
No
Ul
Y
Voltage
208-230/460
Weight
35
Washguard SST All-Stainless Washdown Motors, 3-Phase: .75/.5HP, 1740/1440 RPM, Totally-Enclosed Non-Ventilated (TENV) Enclosure, 56 Frame, RIGID C, 208-230/460V, 3PH, 60/50HZ, Name Plate Amps 2.4-2.3/1.15&2/1, Continuous duty, 1.15 Service Factor, No thermal protection, Ambient 40 C, Reverse Rotation, Shaft Length: 1-7/8, Shaft Diameter: 5/8.

Stainless Steel Tough for demanding washdown applications

  • All exterior components of 300 series stainless steel, including motor frame, endshield and conduit box castings
  • Moisture resistant sealant between frame and endbells
  • Full-fact nameplate is laser-etched on the motor frame
  • Built to withstand the demanding washdown environments found in the food processing, chemical processing and beverage industries
  • No paint or coatings of any type are used on the exterior of the motor
  • Four locations for T-drains provided on each endshield
  • Meets IP55 enclosure protection
  • Three phase motors are suitable for use on VFDs
  • 10:1 ratio for constant or variable torque at 1.0 SF
