OEM#: 122213.00New OEM Original Outright

WASHDOWN MOTOR 3 HP 3490 145JM 230/460V by Leeson

Your price:
$3,489.35 eachReady to ship
HomeLeeson12221300
WASHDOWN MOTOR 3 HP 3490 145JM 230/460V by Leeson
WASHDOWN MOTOR 3 HP 3490 145JM 230/460V by Leeson

OEM#: 122213.00
WASHDOWN MOTOR 3 HP 3490 145JM 230/460V by Leeson

New OEM Original Outright
Your price:
$3,489.35 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 122213.00 Key Specs
Item
WASHDOWN MOTOR 3 HP 3490 145JM 230/460V
OEM
Leeson
OEM #
122213.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Washguard
Body Diameter
6 19/32 in
CC Number
CC005A
Conduit Box
Oversized Stainless Steel BICB and Threaded Cover with O Ring
Country of Origin
USA
Drain Plugs
None
Duty
Continuous
Endshields
Stainless Steel
Frame
145JM
Full Load Amps
8/4
Green Certification or Other Recognition
NEMA Premium(R) Rated
HP
3
Hz
60/50
Includes
Removable Hydrophobic Breathers In Opposite Shaft Endbell
Ins. Class
F
Length Less Shaft
12-1/4 in
Max Ambient Temperature
40 Degrees C
Motor Application
Washdown
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Stainless Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Face/Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed and Drilled On Center
Motor Shaft Rotation
CWSE
Motor Thermal Protection
None
NEMA Design
B
Nameplate RPM
3490
Nominal Efficiency
86.5 %
Overall Length
16-1/2 in
Phase
3
RPM Range
3001-3600
Shaft Diameter
7/8 in
Shaft Length
4-1/4 in
Shaft Material
303 Stainless Steel
Standards
CSA (LR2025), UL (E49747)
Voltage
230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
