OEM#: 116644.00New OEM Original Outright

MOTOR 1/2 HP 1725 56C 208-230/460V by Leeson

Your price:
$929.84 eachReady to ship
HomeLeeson11664400
MOTOR 1/2 HP 1725 56C 208-230/460V by Leeson
MOTOR 1/2 HP 1725 56C 208-230/460V by Leeson

OEM#: 116644.00
MOTOR 1/2 HP 1725 56C 208-230/460V by Leeson

New OEM Original Outright
Your price:
$929.84 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 116644.00 Key Specs
Item
MOTOR 1/2 HP 1725 56C 208-230/460V
OEM
Leeson
OEM #
116644.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
General Purpose
Country of Origin
USA
Frame
56C
Full Load Amps
2/1
HP
1/2
Hz
60/50
Ins. Class
F
Length Less Shaft
8-15/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
Washdown
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Type
Face
Motor Service Factor
1.15
Motor Shaft Rotation
CWSE
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
74 %
Phase
3
RPM Range
1701-1800
Shaft Diameter
5/8 in
Shaft Length
1-15/16 in
Voltage
230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
