OEM#: 114630.00New OEM Original Outright
3/4HP, 208-230/460V, 1725/1425RPM, EPFC, RIGID C MOUNT by Leeson
Your price:
$1,381.34 each
OEM#: 114630.003/4HP, 208-230/460V, 1725/1425RPM, EPFC, RIGID C MOUNT by Leeson
New OEM Original Outright
Your price:
$1,381.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Leeson Explosion-Proof, 3-Phase, C Face Motor With Base - .75 HP - 3450 / 2850 RPM
Leeson Explosion-Proof, 3-Phase, C Face Motors With Base are solidly made for long lasting durability and dependability. Division I, Division II, Class I, Groups C&D Class II, Groups F & G with Conduit Box for hazardous locations. Rugged mechanical construction meeting all requirements for safety. Double shielded, pre-lubricated ball bearings. Inherent automatic overload protection. Explosion-proof conduit box included. Division I areas are environments where a hazard is present continuously or would be subject to fire or explosion if the hazard was present as a result of an accident or uncommon occurrence. Division II areas are environments where the threat of fire or explosion is not normally present and not likely to result in the event of an abnormal occurrence. Note: These motors must be applied in accordance with the National Electrical Code, Article #500. 56 Frame. UL and CSA listed.
Leeson Explosion-Proof, 3-Phase, C Face Motors With Base are solidly made for long lasting durability and dependability. Division I, Division II, Class I, Groups C&D Class II, Groups F & G with Conduit Box for hazardous locations. Rugged mechanical construction meeting all requirements for safety. Double shielded, pre-lubricated ball bearings. Inherent automatic overload protection. Explosion-proof conduit box included. Division I areas are environments where a hazard is present continuously or would be subject to fire or explosion if the hazard was present as a result of an accident or uncommon occurrence. Division II areas are environments where the threat of fire or explosion is not normally present and not likely to result in the event of an abnormal occurrence. Note: These motors must be applied in accordance with the National Electrical Code, Article #500. 56 Frame. UL and CSA listed.
Technical Specs
P/N: 114630.00 Key Specs
Item
3/4HP, 208-230/460V, 1725/1425RPM, EPFC, RIGID C MOUNT
OEM
Leeson
OEM #
114630.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Compatible With/Replaces
Baldor CM7010A
Construction
Rolled Steel
Country of Origin
USA
Csa
Y
Design
Sq Cage Inductor Run
Duty
Continuous
Efficiency
75.5
Efficiency Type
Standard
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
2.9-3/1.5
Frame
56
Hertz
60/50
Horsepower
3/4
Is_Motor
Yes
Leeson Model No.
A6T17XK11CC
Motor Rpm 50Hz
1425
Motor Rpm 60Hz
1725
Mounting
C-Face Rigid
Phase
3
Rotation
CCW/CW
Rpm
1725/1425
Rpm Range
1701-1800
Service Factor
1
Shaft Diameter
5/8
Shaft Length (in)
1-7/8
Thermal Protection
Automatic
Ul
Y
Upc
69172001417
Voltage
208-230/460
Weight
45
Leeson Explosion-Proof, 3-Phase, C Face Motor With Base - .75 HP - 3450 / 2850 RPM
Leeson Explosion-Proof, 3-Phase, C Face Motors With Base are solidly made for long lasting durability and dependability. Division I, Division II, Class I, Groups C&D Class II, Groups F & G with Conduit Box for hazardous locations. Rugged mechanical construction meeting all requirements for safety. Double shielded, pre-lubricated ball bearings. Inherent automatic overload protection. Explosion-proof conduit box included. Division I areas are environments where a hazard is present continuously or would be subject to fire or explosion if the hazard was present as a result of an accident or uncommon occurrence. Division II areas are environments where the threat of fire or explosion is not normally present and not likely to result in the event of an abnormal occurrence. Note: These motors must be applied in accordance with the National Electrical Code, Article #500. 56 Frame. UL and CSA listed.
Leeson Explosion-Proof, 3-Phase, C Face Motors With Base are solidly made for long lasting durability and dependability. Division I, Division II, Class I, Groups C&D Class II, Groups F & G with Conduit Box for hazardous locations. Rugged mechanical construction meeting all requirements for safety. Double shielded, pre-lubricated ball bearings. Inherent automatic overload protection. Explosion-proof conduit box included. Division I areas are environments where a hazard is present continuously or would be subject to fire or explosion if the hazard was present as a result of an accident or uncommon occurrence. Division II areas are environments where the threat of fire or explosion is not normally present and not likely to result in the event of an abnormal occurrence. Note: These motors must be applied in accordance with the National Electrical Code, Article #500. 56 Frame. UL and CSA listed.
