OEM#: 110088.00New OEM Original Outright
GENERAL PURPOSE FARM DUTY MOTOR 1 HP by Leeson
Your price:
$534.87 each $862.06 Savings: $327.19 (38%)
OEM#: 110088.00GENERAL PURPOSE FARM DUTY MOTOR 1 HP by Leeson
New OEM Original Outright
Your price:
$534.87 each
$862.06 Savings: $327.19 (38%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 110088.00 Key Specs
Item
GENERAL PURPOSE FARM DUTY MOTOR 1 HP
OEM
Leeson
OEM #
110088.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Duty
Continuous
Finish
Enamel
Frame
56
Full Load Amps
14/7
HP
1
Hz
60
Ins. Class
B
Item - Farm Duty Motors
High Torque Farm Duty Motor
Length Less Shaft
10-1/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
Farm Duty
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Sub Application
High Torque
Motor Thermal Protection
Manual
Nameplate RPM
1725
Nominal Efficiency
74 %
Overall Length
12 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-15/16 in
Standards
CSA (LR2025), UL (E49747)
Voltage
115/230
Voltage Compatibility
115, 115/230, 120, 120/240, 230, 240
