OEM#: 110013.00New OEM Original Outright

3/4HP, 115/208-230V, 1725RPM, TEFC, RIGID MOUNT, 1.15 SF, 70 EFF by Leeson

Your price:
$620.64 eachReady to ship
HomeLeeson11001300
3/4HP, 115/208-230V, 1725RPM, TEFC, RIGID MOUNT, 1.15 SF, 70 EFF by Leeson
3/4HP, 115/208-230V, 1725RPM, TEFC, RIGID MOUNT, 1.15 SF, 70 EFF by Leeson

OEM#: 110013.00
3/4HP, 115/208-230V, 1725RPM, TEFC, RIGID MOUNT, 1.15 SF, 70 EFF by Leeson

New OEM Original Outright
Your price:
$620.64 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
General Purpose, Capacitor Start-Inductor Run Motor: 3/4HP, 1725 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 56 Frame, Rigid Mount, 115/208-230V, 1PH, 60HZ, Name Plate Amps 10.8/5.4, Continuous duty, 1.15 Service Factor, No thermal protection, Efficiency: 70, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length 1-7/8, Shaft Diameter 5/8.

Totally enclosed fan cooled (TEFC) enclosure has no vent openings, and is tightly enclosed to prevent the free exchange of air, but is not airtight. An external fan is an integral part of the motor and provides cooling by blowing air around the outside frame of the motor. Suitable for use where exposed to dirt or dampness, but NOT very moist or hazardous (explosive) locations.
Rigid base allows motor to be rigidly mounted on equipment.

Technical Specs
P/N: 110013.00 Key Specs
Item
3/4HP, 115/208-230V, 1725RPM, TEFC, RIGID MOUNT, 1.15 SF, 70 EFF
OEM
Leeson
OEM #
110013.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Compatible With/Replaces - 1
Baldor L3507, WEG .7518ES1BB56, US Motors T34C2J, Marathon C268
Compatible With/Replaces - 2
Baldor, L3507
Csa
Y
Design
Capacitor Start Inductor Run
Duty
Continuous
Efficiency Type
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
10.8/5.4-5.7
Fl Efficiency
70
Frame
56
Frame Material
Rolled Steel
Hertz
60
Horsepower
3/4
Is_Motor
Yes
Leeson Model No.
C6C17FB2KK
Motor Rpm 60Hz
1725
Mounting
Rigid
Nameplate Rpm
1725
Phase
1
Rotation
CCW
Rpm Range
1701-1800
Service Factor
1.15
Shaft Diameter
5/8
Shaft Length
1-7/8
Thermal Protection
No
Ul
Y
Upc
69172000732
Voltage
115/208-230
Weight
32
General Purpose, Capacitor Start-Inductor Run Motor: 3/4HP, 1725 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 56 Frame, Rigid Mount, 115/208-230V, 1PH, 60HZ, Name Plate Amps 10.8/5.4, Continuous duty, 1.15 Service Factor, No thermal protection, Efficiency: 70, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length 1-7/8, Shaft Diameter 5/8.

Totally enclosed fan cooled (TEFC) enclosure has no vent openings, and is tightly enclosed to prevent the free exchange of air, but is not airtight. An external fan is an integral part of the motor and provides cooling by blowing air around the outside frame of the motor. Suitable for use where exposed to dirt or dampness, but NOT very moist or hazardous (explosive) locations.
Rigid base allows motor to be rigidly mounted on equipment.
