OEM#: 107007.00New OEM Original Outright
1/3 HP, 288 RPM, 115/208-230V, 1-PHASE, TEFC, P1100, 6:1 RATIO, 70 IN-LBS by Leeson
Your price:
$1,152.70 eachEstimated to ship by 05/10 if ordered before 10:30 AM EST
OEM#: 107007.001/3 HP, 288 RPM, 115/208-230V, 1-PHASE, TEFC, P1100, 6:1 RATIO, 70 IN-LBS by Leeson
New OEM Original Outright
Your price:
$1,152.70 each
Estimated to ship by 05/10 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Leeson 107007.00, 1/3 HP, 288 RPM, 115/208-230V, 1-Phase, TEFC, P1100, 6:1 Ratio, 70 In-Lbs
AC Gearmotor with Parallel Shaft. 1/3HP, 288 RPM, Gear Ratio 6 to 1, Overhung Load 400 Pounds, 70 Lb. In. Full Load Torque, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 48Y Frame, 115/208-230V, 1PH, 60HZ, Name Plate Amps 6.2, Continuous Duty, Efficiency Type Standard.
Fractional horsepower AC gearmotors are totally enclosed for continuous duty, general purpose applications. Rated for 60 Hz input. Gearbox has rugged aluminum die cast housing to provide maximum gear and bearing support and precision machined gearing hardened for maximum load capability. All gearing designed and rated to AGMA Class 9 standards and to withstand momentary shock overload of 200%. Oversized output bearings increase overhung load capacity and give longer life. High-carbon alloy output shaft provides maximum strength and rigidity. All needle bearing journals are precision ground after heat treating, to provide maximum finish and fit. Heavy-duty industrial oil seals help keep lubricant in and dirt out. Gears and bearings are splash lubricated with permanent, heavy-duty gear oil.
These gearmotors are designed for mounting at any angle, but shaft-up with motor below gearhead is not recommended. P1100 AC gearmotors have the same mounting dimensions as Bison 482 gearmotors and many Dayton gearmotors. Includes conduit box.
| Compatibility |
| Bison: 014-482-3006(Leeson motor is capacitor start/induction run design ) |
| Grainger/Dayton: 2Z845(Leeson motor is capacitor start/induction run design, Leeson motor is dual voltage rated - 115/230 ) |
| Minarik: 508-01-631(Leeson motor is capacitor start/induction run design, Leeson motor is dual voltage rated - 115/230 ) |
Features
- Manufacturer: Leeson
- Condition: New OEM Original
- Purchase Type: Outright
- Warranty: Mfr Warranty
- Returnable: No
Technical Specs
P/N: 107007.00 Key Specs
Item
1/3 HP, 288 RPM, 115/208-230V, 1-PHASE, TEFC, P1100, 6:1 RATIO, 70 IN-LBS
OEM
Leeson
OEM #
107007.00
Condition
New OEM Original
Returnable
No
Ambient Temp C
40
Csa
Yes
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6.2/3.1
Frame Material
Steel
Gear Motor Rpm
288
Gearhead / Shaft Type
Parallel
Hertz
60
Horsepower
1/3
Hp Range
1/3 to 3/8
Insulation Class
B
Is_Motor
Yes
Model
C4C17FZ32
Output Torque (In-Lbs)
70
Overhung Load (Lbs.)
400
Phase
1
Ratio To 1
6
Rotation
Reversible
Rpm Range
0-1000
Series
P1100
Service Factor
1.15
Type & Frame Style
P1102-48
Ul
Yes
Voltage
115/208-230
Weight Lbs
29
Leeson 107007.00, 1/3 HP, 288 RPM, 115/208-230V, 1-Phase, TEFC, P1100, 6:1 Ratio, 70 In-Lbs
AC Gearmotor with Parallel Shaft. 1/3HP, 288 RPM, Gear Ratio 6 to 1, Overhung Load 400 Pounds, 70 Lb. In. Full Load Torque, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 48Y Frame, 115/208-230V, 1PH, 60HZ, Name Plate Amps 6.2, Continuous Duty, Efficiency Type Standard.
Fractional horsepower AC gearmotors are totally enclosed for continuous duty, general purpose applications. Rated for 60 Hz input. Gearbox has rugged aluminum die cast housing to provide maximum gear and bearing support and precision machined gearing hardened for maximum load capability. All gearing designed and rated to AGMA Class 9 standards and to withstand momentary shock overload of 200%. Oversized output bearings increase overhung load capacity and give longer life. High-carbon alloy output shaft provides maximum strength and rigidity. All needle bearing journals are precision ground after heat treating, to provide maximum finish and fit. Heavy-duty industrial oil seals help keep lubricant in and dirt out. Gears and bearings are splash lubricated with permanent, heavy-duty gear oil.
These gearmotors are designed for mounting at any angle, but shaft-up with motor below gearhead is not recommended. P1100 AC gearmotors have the same mounting dimensions as Bison 482 gearmotors and many Dayton gearmotors. Includes conduit box.
| Compatibility |
| Bison: 014-482-3006(Leeson motor is capacitor start/induction run design ) |
| Grainger/Dayton: 2Z845(Leeson motor is capacitor start/induction run design, Leeson motor is dual voltage rated - 115/230 ) |
| Minarik: 508-01-631(Leeson motor is capacitor start/induction run design, Leeson motor is dual voltage rated - 115/230 ) |
