OEM#: 102916.00New OEM Original Outright

SINGLE PHASE GENERAL PURPOSE MOTOR 1/4HP, 1725RPM, 56, TEFC, 115/208-230V, 60HZ by Leeson

Your price:
$522.39 eachReady to ship
HomeLeeson10291600
SINGLE PHASE GENERAL PURPOSE MOTOR 1/4HP, 1725RPM, 56, TEFC, 115/208-230V, 60HZ by Leeson
SINGLE PHASE GENERAL PURPOSE MOTOR 1/4HP, 1725RPM, 56, TEFC, 115/208-230V, 60HZ by Leeson

OEM#: 102916.00
SINGLE PHASE GENERAL PURPOSE MOTOR 1/4HP, 1725RPM, 56, TEFC, 115/208-230V, 60HZ by Leeson

New OEM Original Outright
Your price:
$522.39 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 102916.00 Key Specs
Item
SINGLE PHASE GENERAL PURPOSE MOTOR 1/4HP, 1725RPM, 56, TEFC, 115/208-230V, 60HZ
OEM
Leeson
OEM #
102916.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Applications
Gear Reducers, Pumps, Machine Tools, Fans And Blowers, Material Handling, Compre
Compatible With/Replaces - 1
Baldor CL3403, WEG .2518ES1BB56C
Country of Origin
Mexico
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
5.4/2.4-2.7
Frame
S56C
Frame Material
Rolled Steel
Hertz
60
Horsepower
1/4
Is_Motor
Yes
Motor Rpm 60Hz
1725
Mounting
C-Face Rigid
Nameplate Rpm
1725
Phase
1
Rpm Range
1701-1800
Service Factor
1.15
Voltage
115/208-230
