OEM#: 101585.00New OEM Original Outright

1/2HP, 115V, 1725RPM, DP, RESILIENT BASE MOUNT, 1.35 SF, 76 EFF. by Leeson

Your price:
$663.24 eachReady to ship
HomeLeeson10158500
1/2HP, 115V, 1725RPM, DP, RESILIENT BASE MOUNT, 1.35 SF, 76 EFF. by Leeson
1/2HP, 115V, 1725RPM, DP, RESILIENT BASE MOUNT, 1.35 SF, 76 EFF. by Leeson

OEM#: 101585.00
1/2HP, 115V, 1725RPM, DP, RESILIENT BASE MOUNT, 1.35 SF, 76 EFF. by Leeson

New OEM Original Outright
Your price:
$663.24 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
General Purpose, Capacitor Start-Capacitor Run Motor: 1/2HP, 1725 RPM, Drip-Proof (DP) Enclosure, 48 Frame, Resilient Base Mount, 115V, 1PH, 60HZ, Name Plate Amps 4.6, Continuous duty, 1.35 Service Factor, Automatic thermal protection, Efficiency: 76, Efficiency Type: NEMA Premium, Ambient 40 C, Selective CCW Rotation, Shaft Length 1-1/2, Shaft Diameter 1/2.

Drip proof (DP)enclosure has vents in end shield and/or frame to prevent drops of liquid from falling into motor within a 15 degree angle from vertical. Designed for use in areas that are reasonably dry, clean, and well ventilated (usually indoors). If installed outdoors, it is recommended that the motor be protected with a cover that does not restrict the flow of air to the motor.

Technical Specs
P/N: 101585.00 Key Specs
Item
1/2HP, 115V, 1725RPM, DP, RESILIENT BASE MOUNT, 1.35 SF, 76 EFF.
OEM
Leeson
OEM #
101585.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Compatible With/Replaces - 1
Grainger/Dayton, 4K103, 4K715
Country of Origin
Mexico
Csa
Y
Design
Capacitor Start Capacitor Run
Duty
Continuous
Efficiency Type
NEMA Premium
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
4.60
Fl Efficiency
76
Frame
48
Frame Material
Rolled Steel
Hertz
60
Horsepower
1/2
Is_Motor
Yes
Leeson Model No.
A4K17DR6GG
Motor Rpm 60Hz
1725
Mounting
Resilient Base
Nameplate Rpm
1725
Phase
1
Rotation
CCW
Rpm Range
1701-1800
Service Factor
1.35
Shaft Diameter
1/2
Shaft Length
1-1/2
Thermal Protection
Automatic
Ul
Y
Upc
69172000574
Voltage
115
Weight
28
General Purpose, Capacitor Start-Capacitor Run Motor: 1/2HP, 1725 RPM, Drip-Proof (DP) Enclosure, 48 Frame, Resilient Base Mount, 115V, 1PH, 60HZ, Name Plate Amps 4.6, Continuous duty, 1.35 Service Factor, Automatic thermal protection, Efficiency: 76, Efficiency Type: NEMA Premium, Ambient 40 C, Selective CCW Rotation, Shaft Length 1-1/2, Shaft Diameter 1/2.

Drip proof (DP)enclosure has vents in end shield and/or frame to prevent drops of liquid from falling into motor within a 15 degree angle from vertical. Designed for use in areas that are reasonably dry, clean, and well ventilated (usually indoors). If installed outdoors, it is recommended that the motor be protected with a cover that does not restrict the flow of air to the motor.
