OEM#: 096016.00New OEM Original Outright
1/3 HP, 345 RPM, 230/460V, 3-PHASE, TEFC, PE350, 5:1 RATIO, 55 IN-LBS by Leeson
Your price:
$1,132.35 each
OEM#: 096016.001/3 HP, 345 RPM, 230/460V, 3-PHASE, TEFC, PE350, 5:1 RATIO, 55 IN-LBS by Leeson
New OEM Original Outright
Your price:
$1,132.35 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Design Specifications:
- Sub-FHP AC gearmotors.
- Totally enclosed for continuous duty, general purpose applications.
- All rated for 60/50 Hz operation except hi-torque single-phase which are 60 Hz only.
- Gearbox has rugged aluminum die cast housing, for maximum gear and bearing support.
- Precision machined gearing, hardened for maximum load capability.
- All gearing designed and rated to AGMA
- Class 9 standards and to withstand momentary shock overload of 200%.
- Oversized output bearings for greater overhung load capacity and longer life.
- High-carbon alloy output shaft provides maximum strength and rigidity. All needle bearing journals are precision-ground after heat treating, to provide maximum finish and fit.
- Single lip, spring loaded, heavy-duty industrial oil seals help keep lubricant in and dirt out.
- Gears and bearings are splash lubricated with permanent, heavy-duty gear oil.
Technical Specs
P/N: 096016.00 Key Specs
Item
1/3 HP, 345 RPM, 230/460V, 3-PHASE, TEFC, PE350, 5:1 RATIO, 55 IN-LBS
OEM
Leeson
OEM #
096016.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Country of Origin
USA
Csa
Yes
Duty
Continuous
Enclosure
TEFC
Fl Amps
1.6/0.8
Frame Material
Steel
Gear Motor Rpm
345
Gearhead / Shaft Type
Parallel
Hertz
60
Horsepower
1/3
Hp Range
1/3 to 3/8
Insulation Class
F
Model
C42T17FZ17
Output Torque (In-Lbs)
55
Overhung Load (Lbs.)
300
Phase
3
Ratio To 1
5
Rotation
Reversible
Series
PE350
Service Factor
1
Type & Frame Style
PE352-42
Ul
Yes
Voltage
230/460
Weight Lbs
30
Design Specifications:
- Sub-FHP AC gearmotors.
- Totally enclosed for continuous duty, general purpose applications.
- All rated for 60/50 Hz operation except hi-torque single-phase which are 60 Hz only.
- Gearbox has rugged aluminum die cast housing, for maximum gear and bearing support.
- Precision machined gearing, hardened for maximum load capability.
- All gearing designed and rated to AGMA
- Class 9 standards and to withstand momentary shock overload of 200%.
- Oversized output bearings for greater overhung load capacity and longer life.
- High-carbon alloy output shaft provides maximum strength and rigidity. All needle bearing journals are precision-ground after heat treating, to provide maximum finish and fit.
- Single lip, spring loaded, heavy-duty industrial oil seals help keep lubricant in and dirt out.
- Gears and bearings are splash lubricated with permanent, heavy-duty gear oil.
