OEM#: RTFH4S-WW-B14KNew OEM Original Outright
CORD REEL 50FT 14 AWG BARE 600VAC by KH Industries
Your price:
$1,728.27 each $1,857.89 Savings: $129.62 (7%)
OEM#: RTFH4S-WW-B14KCORD REEL 50FT 14 AWG BARE 600VAC by KH Industries
New OEM Original Outright
Your price:
$1,728.27 each
$1,857.89 Savings: $129.62 (7%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: RTFH4S-WW-B14K Key Specs
Item
CORD REEL 50FT 14 AWG BARE 600VAC
OEM
KH Industries
OEM #
RTFH4S-WW-B14K
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
UL, CSA, NEMA 4X
Cord Color
Black
Cord Included
Yes
Country of Origin
USA
Enclosure Rating
NEMA 4X
Feeder Cord Ending
Flying Lead
Feeder Cord Ending Configuration
Flying Lead
Includes
Constant-Tension, Engineered for Stretch Application Use
Location
Outdoor
Maximum Amps
12
Number of Conductors
4
Number of Outlets
0
Overall Depth
14-1/2 in
Overall Height
15 in
Overall Width
14-1/2 in
Reel Color
Yellow
Reel Material
Steel
Reel Mounting
Bench, Ceiling, Wall
Retractable Cord Ending
Flying Lead
Retractable Cord Ending Configuration
Flying Lead
Retractable Cord Length
50 ft.
Slip Ring Rating
35A @ 600V
Special Features
Engineered for Stretch Application Use
Temperature Rating
-22 Degrees to 194 Degrees F
Tension Method
Constant Tension
Trade Designation
SOOW
Voltage
600VAC
Winding Method
Spring Retraction
Wire Size
14 AWG
