RELAY MODULE, 15 TO 32 VDC, 6.5 MA, HIGH NOISE IMMUNITY, 32 TO 120 DEG F, MEETS FM, UL

HomeJohnson Controlsm300rj
RELAY MODULE, 15 TO 32 VDC, 6.5 MA, HIGH NOISE IMMUNITY, 32 TO 120 DEG F, MEETS FM, UL
RELAY MODULE, 15 TO 32 VDC, 6.5 MA, HIGH NOISE IMMUNITY, 32 TO 120 DEG F, MEETS FM, UL

RELAY MODULE, 15 TO 32 VDC, 6.5 MA, HIGH NOISE IMMUNITY, 32 TO 120 DEG F, MEETS FM, UL

Product Overview

The M300RJ(A) Addressable Relay Module provides the system with a dry-contact output for activating a variety of auxiliary devices, such as fans, dampers, control equipment, etc. Addressability allows the dry contact to be activated, either manually or through panel programming, on a select basis.

  • Built-in type identification automatically identifies these devices to the control panel
  • Internal circuitry and relay powered directly by two-wire slc loop. The m300cj(a) module requires power (for horns, strobes, etc.), or audio
  • Led blink may be deselected globally
  • High noise immunity (EMF/RFI)
  • Integral LED “blinks” green each time a communication is received from the control panel and turns on in steady red when activated
  • Wide viewing angle of LED
  • SEMS screws with clamping plates for wiring ease
  • Direct-dial entry of address 01– 159 for FlashScan loops, 01 – 99 for CLIP mode loops
  • Speaker, and audible/visual applications may be wired forClass B or A (Style Y or Z)

    • Technical Specs
    P/N: M300RJ Key Specs
    Item
    RELAY MODULE, 15 TO 32 VDC, 6.5 MA, HIGH NOISE IMMUNITY, 32 TO 120 DEG F, MEETS FM, UL
    OEM
    Johnson Controls
    OEM #
    M300RJ
    Returnable
    No
    Warranty
    Product Type
    Module
