OEM#: P499VCP-107KNew OEM Original Outright
PRESSURE TRANSDUCER 0 TO 750 PSIG by Johnson Controls
Your price:
$222.25 each $270.71 Savings: $48.46 (18%)
OEM#: P499VCP-107KPRESSURE TRANSDUCER 0 TO 750 PSIG by Johnson Controls
New OEM Original Outright
Your price:
$222.25 each
$270.71 Savings: $48.46 (18%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: P499VCP-107K Key Specs
Item
PRESSURE TRANSDUCER 0 TO 750 PSIG
OEM
Johnson Controls
OEM #
P499VCP-107K
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Accuracy - Transmitter
+/-1.00% Full Scale
Compatible With
All Media Compatible with 17-4PH Stainless Steel, Including Ammonia
Electrical Connections - Transmitter
Packard Connector with 6-1/2 ft Wiring Harness
For Use With
Any Corrosive or Non-Corrosive Pressure Medium That is Compatible with 17-4PH Stainless Steel, Including Water, Condensate, Carbon Dioxide, Glycol, Most Refrigerants Including Ammonia, and Many Other Compatible Fluids and Gases
Housing
17-4PH Stainless Steel Construction
Includes
2m Wiring Harness
Loop Resistance
Minimum Between Transducer Body and Any Wire: 100 megaohm @ 500V DC
Max Pressure (PSI)
1,500 psi
Operating Temperature - Transmitter
-40 Degrees to 185 Degrees F
Output - Transmitter
0 to 10V DC
Power Required - Transmitters
12 to 30V DC
Process Connection Size - Transmitter
1/4 in
Process Connection Type - Transmitter
SAE Flare Internal Thread
Range Units - Transmitter
psig
Range Values - Transmitter
0 to 750
Safety Rating - Transmitter
Class I, Div. 2, Groups A, B, C, D
Transmitter Type
Pressure Transmitter
Wetted Materials - Transmitters
17-4PH Stainless Steel
Wiring Entry - Transmitter
None
