OEM#: PVM18CNew OEM Original Outright
INDSTRL MISTING FAN 18 BLDE DIA 3SPD by JJS Technical Services
Your price:
$1,545.42 each
OEM#: PVM18CINDSTRL MISTING FAN 18 BLDE DIA 3SPD by JJS Technical Services
New OEM Original Outright
Your price:
$1,545.42 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: PVM18C Key Specs
Item
INDSTRL MISTING FAN 18 BLDE DIA 3SPD
OEM
JJS Technical Services
OEM #
PVM18C
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Air Flow
1,400/1,800/2,200 cfm
Air Velocity @ 20 Ft.
190/270/310 fpm
Amps
1.5/1.3/1
Assembly
Assembly Required
Bearing Type
Sealed Ball
Blade Diameter
18 in
Blade Material
Steel
Country of Origin
China
Depth
26 1/2 in
Drive Type
Direct Drive
Environmental Applications
Industrial
Fan Cord Length
25 ft
Fan Housing Material
Steel
Fan Mounting Location
Pedestal
Guard Material
Steel
Height
Adj 53 to 72 in
Height Adjustment
53 to 72 in
Hz
60 Hz
Includes
(1) Extra Nozzle, (2) Plugs, 14 gal Tank, 7 hr Run Time, 8 in Rubber Casters, High Pressure Water Pump, Power Cut Off Tip Switch
Max. Ambient Temp.
107 Degrees F
Motor Enclosure
Totally Enclosed Air-Over
Motor HP
1/10 hp
Motor Insulation
Class A
Motor Type
Permanent Split Capacitor
NEMA Plug Configuration
5-15P with GFCI
Number of Blades
3
Number of Conductors
3
Number of Speeds
3
Oscillation
Non-Oscillating
Phase
1
RPM
1000/1400/1570
Shaft Dia.
1/2 in
Sound Level
60/52 dBA
Standards
OSHA Guard, UL507 Motor
Thermal Protection
Auto
Voltage
115V AC
Watts
130
Wheeled Base
Mobile
Width
24 in
Wire Guard Finish
White Powder Coated
