OEM#: IDP-22New OEM Original Outright

FLOOR DRILL PRESS BELT 21-7/8 1-1/2 HP by Jet

Your price:
$3,583.32 eachReady to ship
HomeJetidp22
FLOOR DRILL PRESS BELT 21-7/8 1-1/2 HP by Jet
FLOOR DRILL PRESS BELT 21-7/8 1-1/2 HP by Jet

OEM#: IDP-22
FLOOR DRILL PRESS BELT 21-7/8 1-1/2 HP by Jet

New OEM Original Outright
Your price:
$3,583.32 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: IDP-22 Key Specs
Item
FLOOR DRILL PRESS BELT 21-7/8 1-1/2 HP
OEM
Jet
OEM #
IDP-22
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps AC
7.6
Base Size
22-5/8 in x 19-7/16 in x 3-3/8 in
Capacity Cast Iron
1-1/4 in
Capacity Steel
1 in
Chuck Size
5/8 in
Column Diameter
3-5/8 in
Corded/Cordless
Corded
Country of Origin
Taiwan
Drill Press Product Grouping
General Purpose Drill Presses
Drive Type
Belt
Hz
60
Includes
Chuck with Key, Arbor, Wrench, Drift Key, Hex Wrenches
Max Spindle To Base
48-1/2 in
Motor HP
1-1/2
Number of Speeds
12
Number of T-Slots
3
Overall Depth
35 in
Overall Height
67 in
Overall Width
19 in
Phase
1
Power Down Feed Included
No
Quill Diameter
2-5/8 in
Spindle Speed
275 to 3050
Spindle Taper
3MT
Spindle Travel
4-13/16 in
Spindle to Table
28 in
Swing
21-7/8 in
Table Slot Size
5/8 in x 1 in
Table Work Surface
18-5/8 in x 16-1/8 in
Tilting Angle
45 Degrees
Voltage
115/230
