OEM#: 690940New OEM Original Outright
JTM-1050 MILL WITH 3-AXIS ACU-RITE G-2 MILLPWR CNC by Jet
0
OEM#: 690940JTM-1050 MILL WITH 3-AXIS ACU-RITE G-2 MILLPWR CNC by Jet
New OEM Original Outright
Asset Information
ADD TO LIST
Technical Specs
P/N: 690940 Key Specs
Item
JTM-1050 MILL WITH 3-AXIS ACU-RITE G-2 MILLPWR CNC
OEM
Jet
OEM #
690940
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Cnc Package
ACU-RITE MILLPWR® G2
Collet Capacity
1/8 - 7/8
Country of Origin
Taiwan
Distance Spindle To Column (Max.) (In.)
26
Distance Spindle To Column (Min.) (In.)
5-1/2
Dro
3-AXIS ACU-RITE MILLPWR® G2
Head Movement (Deg.)
90° R & L, 45° F & B
Height Inches
87
Length Inches
96
Max Distance Spindle To Table (In)
19
Motor Horsepower
3
Motor Phase
Three
Motor Voltage
230/460
Number Of Axis
3
Number Of Spindle Speeds
Variable
Powerfeed
X, Y & Z-Axis
Prewired
230V
Quill Diameter (In.)
3-3/8
Quill Down Feed Rates (Ipr)
.0015 - .003 - .006
Range Of Spindle Speeds (Rpm)
70 - 3,800
Spindle Taper
R-8
Spindle Travel (In.)
5
Style
CNC
T-Slots Centers (In.)
2-1/2
T-Slots Number And Size (In.)
3 and 5/8
Table Cross Travel (In.)
15-1/4
Table Longitudinal Travel (In.)
35
Table Size Inches
10 x 50
Travel Of Knee (In.)
14-1/4
Travel Of Ram (In.)
20-1/2
Weight Lbs
3,200
Width Inches
69
Work Table Weight Capacity (Lbs.)
720
