OEM#: 354301New OEM Original Outright

JET IDP-22 22" INDUSTRIAL FLOOR MODEL DRILL PRESS 1-1/2HP, 115/230V, 1PH by Jet

Your price:
$4,200.14 eachReady to ship
HomeJet354301
JET IDP-22 22" INDUSTRIAL FLOOR MODEL DRILL PRESS 1-1/2HP, 115/230V, 1PH by Jet
JET IDP-22 22" INDUSTRIAL FLOOR MODEL DRILL PRESS 1-1/2HP, 115/230V, 1PH by Jet

OEM#: 354301
JET IDP-22 22" INDUSTRIAL FLOOR MODEL DRILL PRESS 1-1/2HP, 115/230V, 1PH by Jet

New OEM Original Outright
Your price:
$4,200.14 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 354301 Key Specs
Item
JET IDP-22 22" INDUSTRIAL FLOOR MODEL DRILL PRESS 1-1/2HP, 115/230V, 1PH
OEM
Jet
OEM #
354301
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Base Dimensions (in)
22-5/8 x 19-7/16 x 3-3/8
Base Slots Number & Size (in)
2 and 5/8
Base Work Table (in)
21-1/2 x 18-5/16
Chuck Size (in)
5/8
Column Diameter (in)
3-5/8
Country of Origin
Taiwan
Distance Column to Spindle (in)
10-7/8
Drilling Capacity (Cast Iron)
1-1/4
Drilling Capacity (Mild Steel)
1
Drills to Center of Circle (in)
22
Height (in)
67
Horsepower
1-1/2
Length (in)
35
Maximum Spindle Distance to Table (in)
28"
Model
IDP-22
Motor Horsepower
1-1/2 HP
Motor Phase
1 Ph
Motor Voltage
115/230V
Number of Spindle Speeds
12
Prewired Voltage
115V
Range of Spindle Speeds (RPM)
175-3050
Spindle Distance to Base (in)
48-1/2
Spindle Taper (in x TPI)
MT-3
Spindle Travel (in)
4-13/16
Style
Floor
Style (Type)
Belt Drive
T-Slots Centers (in)
3/4
T-Slots Number & Size (in)
2 and 5/8
Table Size (L x W) (in)
18-5/8" x 16-1/8"
Weight (lb)
364
Width (in)
19
Worktable Weight Capacity (lb)
176
