OEM#: 354170New OEM Original Outright
JDP-20MF 20 FLOOR DRILL PRESS, 115/230V 1-PHASE by Jet
Your price:
$2,459.29 each
OEM#: 354170JDP-20MF 20 FLOOR DRILL PRESS, 115/230V 1-PHASE by Jet
New OEM Original Outright
Your price:
$2,459.29 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 354170 Key Specs
Item
JDP-20MF 20 FLOOR DRILL PRESS, 115/230V 1-PHASE
OEM
Jet
OEM #
354170
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Base Dimensions Inches
13-5/8 x 22-3/8
Base Slots Number & Size (In.)
2 X 5/8
Base Work Table (In.)
13 X 8-1/2
Chuck Size Inches
3/4
Column Diameter (In.)
3-3/8
Column Diameter Inches
3-3/8
Country of Origin
China
Drilling Capacity Cast Iron
1
Drilling Capacity Mild Steel
3/4
Drills To Center Of Circle (In.)
20
Model
JDP-20MF
Motor
1-1/2 HP, 115/230V, 1Ph, Prewired 115V
Motor Horsepower
1.5 HP
Motor Phase
1 Ph
Motor Voltage
115/230V
Number Of Spindle Speeds
12
Prewired
115V
Quill Diameter (In.)
2.44
Quill Travel (In.)
4-5/8
Range Of Spindle Speeds (Rpm)
150 - 4,200
Size
20"
Spindle Distance To Base (In.)
46-3/4
Spindle Distance To Base Inches
46-3/4
Spindle Distance To Table (Max./In.)
29-1/8
Spindle Taper
3 MT
Spindle Travel (In.)
4-5/8
Style
Floor
T-Slots Centers (In.)
3-1/2
T-Slots Number And Size (In.)
6 & 1/2
Table Size (In.)
18-1/2 X 16
Table Size Inches
18-1/2 X 16
Weight Lbs
282
Work Table Weight Capacity (Lbs.)
80
