OEM#: 350128New OEM Original Outright

JMD-18PFN MILLING/DRILLING MACHINE W/NEWALL DP700 DRO, 2 HP by Jet

Your price:
$12,596.90 eachReady to ship
HomeJet350128
JMD-18PFN MILLING/DRILLING MACHINE W/NEWALL DP700 DRO, 2 HP by Jet
JMD-18PFN MILLING/DRILLING MACHINE W/NEWALL DP700 DRO, 2 HP by Jet

OEM#: 350128
JMD-18PFN MILLING/DRILLING MACHINE W/NEWALL DP700 DRO, 2 HP by Jet

New OEM Original Outright
Your price:
$12,596.90 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 350128 Key Specs
Item
JMD-18PFN MILLING/DRILLING MACHINE W/NEWALL DP700 DRO, 2 HP
OEM
Jet
OEM #
350128
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Base Dimensions Inches
15-3/4 X 23-3/4
Column Diameter (In.)
4-1/2
Column Diameter Inches
4-1/2
Country of Origin
China
Drilling Capacity Inches
1-1/4
Dro
Newall DP700
End Milling Capacity Inches
3/4
Face Milling Capacity Inches
3
Height Inches
43.5
Length Inches
42.5
Max Distance Spindle To Table
18
Max Distance Table To Spindle
18
Model
JMD-18PFN
Motor
2 HP, 1 Ph, 230V only
Motor Horsepower
2
Number Of Spindle Speeds
12
Overall Dimensions
L 42-1/2 X W 39-3/4 X H 43-1/2
Powerfeed
Downfeed
Quill Diameter (In.)
3
Quill Diameter Inches
3
Range Of Spindle Speeds (Rpm)
150 - 3,000
Size
15-7/8
Spindle Taper
R-8
Spindle Travel (In.)
5
Swing (In.)
15-7/8
Swing Inches
15-7/8
T-Slots Centers (In.)
1-13/16
T-Slots Number And Size (In.)
4 & 5/8
Table Cross Travel (In.)
7
Table Longitudinal Travel (In.)
20-1/2
Table Size Inches
9-1/2 x 31-3/4
Weight Lbs
944
Width Inches
39.75
Work Table Weight Capacity (Lbs.)
400
