OEM#: 350120New OEM Original Outright

JET JMD-18PFN MILL DRILL 2 HP, 115/230V, 1PH by Jet

Your price:
$15,183.50 eachReady to ship
HomeJet350120
JET JMD-18PFN MILL DRILL 2 HP, 115/230V, 1PH by Jet
JET JMD-18PFN MILL DRILL 2 HP, 115/230V, 1PH by Jet

OEM#: 350120
JET JMD-18PFN MILL DRILL 2 HP, 115/230V, 1PH by Jet

New OEM Original Outright
Your price:
$15,183.50 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 350120 Key Specs
Item
JET JMD-18PFN MILL DRILL 2 HP, 115/230V, 1PH
OEM
Jet
OEM #
350120
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Base Dimensions Inches
15-3/4 x 23-3/4
Belt Table Size (L X W/In.)
9-1/2 x 32-1/4
Column Diameter (In.)
4-1/2
Drilling Capacity Inches
1-1/4
Dro
ACU-RITE VUE
End Milling Capacity Inches
3/4
Face Milling Capacity Inches
3
Max Distance Spindle To Table (In)
18
Model
JMD-18PFN
Motor
2 HP, 115/230V, 1Ph
Motor Horsepower
2
Motor Phase
Single
Motor Voltage
115/230
Number Of Spindle Speeds
12
Overall Dimensions
47 x 40 x 51
Powerfeed
X-Axis
Prewired
115V
Quill Diameter (In.)
3
Range Of Spindle Speeds (Rpm)
150 - 3,000
Spindle Taper (In X Tpi)
R-8
Spindle Travel (In.)
5
Swing (In.)
15-7/8
T-Slot Centers (In)
1-13/16
T-Slots Number And Size (In.)
4, 5/8
Table Longitudinal Travel (In.)
20-1/2
Weight Lbs.
580
Work Table Weight Capacity (Lbs.)
400
