OEM#: W5B-80V-230/1New OEM Original Outright
ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE by Jenny
Your price:
$5,092.83 each
OEM#: W5B-80V-230/1ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE by Jenny
New OEM Original Outright
Your price:
$5,092.83 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: W5B-80V-230/1 Key Specs
Item
ELECTRIC AIR COMPRESSOR 5 HP 2 STAGE
OEM
Jenny
OEM #
W5B-80V-230/1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
(F)NPT Outlet
1/2 in
ASME Tank
Yes
Amps
25.6
Compressor Package Type
Fully Packaged
Control
Pressure Switch/Magnetic Starter
Cylinder Material
Cast Iron
Enclosure
NEMA 1
Finish
Powder Coated
Free Air CFM @ Max. Pressure - Air Compressor
17.5
HP - Air Compressor
5.0 hp
Hz
60
Includes
Magnetic Starter
Input Voltage - Air Compressor
240V AC
Item - Air Compressor
Stationary Air Compressor
Lubrication Type - Air compressor
Splash Lubricated
Motor Type
Open Dripproof
Number of Stages - Air Compressor
2
Off Pressure Switch Setting
175 psi
On Pressure Switch Setting
145 psi
Overall Height
73 in
Overall Length
37 in
Overall Width
25 in
Phase - Electrical
1
Pump Location - Air Compressor
Tank Mounted
Pump Oil Capacity
1.8 qt
Pump RPM
760
Standards
CSA Certified, UL Listed
Style - Air Compressor
Simplex
Tank Size - Air Compressor
80 gal
Tank Style - Air Compressor
Vertical
dBA @ 3 Feet
89
