160 H X 70 W X 35MM D 860MM CABLE LIGHT METER FOR NEONATAL JAUNDICE TREATMENT SYSTEM

160 H X 70 W X 35MM D 860MM CABLE LIGHT METER FOR NEONATAL JAUNDICE TREATMENT SYSTEM
160 H X 70 W X 35MM D 860MM CABLE LIGHT METER FOR NEONATAL JAUNDICE TREATMENT SYSTEM

160 H X 70 W X 35MM D 860MM CABLE LIGHT METER FOR NEONATAL JAUNDICE TREATMENT SYSTEM

Product Overview

The ILT750 Bili Light Meter is the ultimate light measurement solution for your neonatal jaundice treatment system. With the ILT750 bilirubin light meter you no longer need to manually record and calculate multiple measurements to get your irradiance value. Instead simply scan the ILT750 detector over the blanket or under the light source and let the meter do the math for you.

  • Dual units with broad sensitivity range: .08 to 8000 µW/cm2/nm, 3.0 to 300,000 µW/cm2
  • Easy to use device
  • 3-digit display resolution
  • Peak response at 470 nm to match bilirubin action spectrum
  • Compact, easy-to-hold, ergonomic design
  • Cosine corrected sensor for accurate spatial response
  • Band Irradiance (µW/cm2/nm) or Irradiance (W/cm2)
  • Works with traditional sources as well as LED
  • Works on bili blankets, pads or overhead lamps
  • Easy to clean housing
  • Uses AA batteries
  • ISO/IEC 17025:2017 Accredited and NIST Traceable calibration
  • Made in USA

Technical Specs
P/N: ILT750-BILI Key Specs
Item
160 H X 70 W X 35MM D 860MM CABLE LIGHT METER FOR NEONATAL JAUNDICE TREATMENT SYSTEM
OEM
International Light Technology
OEM #
ILT750-BILI
Returnable
No
Warranty
Ambient Temperature
0 to 40°C
Band Irradiance Range
0.08 to 8000µW/cm2/nm
Cable Size
860mm
Current Rating
1nA to 1.65uA
For Use With
For Neonatal Jaundice Treatment System
Irradiance Range
3 to 300,000µW/cm2
Meter Display Size
50 x 32mm
Meter and Sensor Mounted Size
70 x 35 x 205mm
Optical Sensor
420 to 520nm, 470nm Peak
Power Supply
2 AA Batteries
Product Type
Light Meter
Screen Update
0.5sec
Sensor Size
43 x 32 x 65mm
