OEM#: BA1620ZOHNew OEM Original Outright
SHELL TYPE NEEDLE ROLLER BEARING INCH, 1" BORE, 1-1/4 OD, 1.250" WIDTH by IKO International
Your price:
$23.03 each
OEM#: BA1620ZOHSHELL TYPE NEEDLE ROLLER BEARING INCH, 1" BORE, 1-1/4 OD, 1.250" WIDTH by IKO International
New OEM Original Outright
Your price:
$23.03 each
Asset Information
Must purchase minimum of 4
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Shell Type Needle Roller Bearing INCH, 1" Bore, 1-1/4 OD, 1.250" Width, Part# BA1620ZOH
IKO Shell Type Needle Roller Bearing (often called Drawn Cup) consists of outer ring that is made from accurately drawn thin special steel plate, needle rollers and with or without retainer. The Shell Type Needle Roller Bearings have smallest sectional height and weight among all of needle roller bearings, and have relatively high load ratings. Needle roller bearing with retainer can be used for high-speed applications as the retainer and the thrust ring precisely guide the rollers. Shell Type Needle Roller Bearings are not provided with pre-packed lubricant. Proper lubrication must be applied when these bearings are used. Shell Type needle roller bearings are generally used with shafts without inner rings. 0.2?mRa or less shaft surface finish and HRC 58 to 64 shaft hardness are recommended. When these requirements are not possible, use of IKO Inner Rings are recommended.
Accuracy: The outer ring of Shell Type Needle Roller Bearings cannot avoid deformation by heat treatment due to their thin cross sections. It is not appropriate to take a direct measurement on the outer ring. Use Standard Mounting Dimensions shown for shaft and housing diameters. Tolerance of outer ring Width is +0 to -0.20 mm.
IKO Shell Type Needle Roller Bearing (often called Drawn Cup) consists of outer ring that is made from accurately drawn thin special steel plate, needle rollers and with or without retainer. The Shell Type Needle Roller Bearings have smallest sectional height and weight among all of needle roller bearings, and have relatively high load ratings. Needle roller bearing with retainer can be used for high-speed applications as the retainer and the thrust ring precisely guide the rollers. Shell Type Needle Roller Bearings are not provided with pre-packed lubricant. Proper lubrication must be applied when these bearings are used. Shell Type needle roller bearings are generally used with shafts without inner rings. 0.2?mRa or less shaft surface finish and HRC 58 to 64 shaft hardness are recommended. When these requirements are not possible, use of IKO Inner Rings are recommended.
Accuracy: The outer ring of Shell Type Needle Roller Bearings cannot avoid deformation by heat treatment due to their thin cross sections. It is not appropriate to take a direct measurement on the outer ring. Use Standard Mounting Dimensions shown for shaft and housing diameters. Tolerance of outer ring Width is +0 to -0.20 mm.
Technical Specs
P/N: BA1620ZOH Key Specs
Item
SHELL TYPE NEEDLE ROLLER BEARING INCH, 1" BORE, 1-1/4 OD, 1.250" WIDTH
OEM
IKO International
OEM #
BA1620ZOH
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Appropriate Inner Ring
IRB1220
Bore (Fw) (mm/in)
25.400 (1)
Country of Origin
Japan
Dynamic Load Rating (N)
24000
Maximum Housing (mm)
31.764
Maximum Shaft (mm)
25.4
Maximum Speed (RPM) (Grease)
9000
Maximum Speed (RPM) (Oil)
15000
Minimum Housing (mm)
31.739
Minimum Shaft (mm)
25.387
OD (D) (mm (in))
31.750 (1-1/4)
Oil Hole
Yes
Static Load Rating (N)
48500
Width (C) (mm (in))
31.75 (1.250)
IKO Shell Type Needle Roller Bearing INCH, 1" Bore, 1-1/4 OD, 1.250" Width, Part# BA1620ZOH
IKO Shell Type Needle Roller Bearing (often called Drawn Cup) consists of outer ring that is made from accurately drawn thin special steel plate, needle rollers and with or without retainer. The Shell Type Needle Roller Bearings have smallest sectional height and weight among all of needle roller bearings, and have relatively high load ratings. Needle roller bearing with retainer can be used for high-speed applications as the retainer and the thrust ring precisely guide the rollers. Shell Type Needle Roller Bearings are not provided with pre-packed lubricant. Proper lubrication must be applied when these bearings are used. Shell Type needle roller bearings are generally used with shafts without inner rings. 0.2?mRa or less shaft surface finish and HRC 58 to 64 shaft hardness are recommended. When these requirements are not possible, use of IKO Inner Rings are recommended.
Accuracy: The outer ring of Shell Type Needle Roller Bearings cannot avoid deformation by heat treatment due to their thin cross sections. It is not appropriate to take a direct measurement on the outer ring. Use Standard Mounting Dimensions shown for shaft and housing diameters. Tolerance of outer ring Width is +0 to -0.20 mm.
IKO Shell Type Needle Roller Bearing (often called Drawn Cup) consists of outer ring that is made from accurately drawn thin special steel plate, needle rollers and with or without retainer. The Shell Type Needle Roller Bearings have smallest sectional height and weight among all of needle roller bearings, and have relatively high load ratings. Needle roller bearing with retainer can be used for high-speed applications as the retainer and the thrust ring precisely guide the rollers. Shell Type Needle Roller Bearings are not provided with pre-packed lubricant. Proper lubrication must be applied when these bearings are used. Shell Type needle roller bearings are generally used with shafts without inner rings. 0.2?mRa or less shaft surface finish and HRC 58 to 64 shaft hardness are recommended. When these requirements are not possible, use of IKO Inner Rings are recommended.
Accuracy: The outer ring of Shell Type Needle Roller Bearings cannot avoid deformation by heat treatment due to their thin cross sections. It is not appropriate to take a direct measurement on the outer ring. Use Standard Mounting Dimensions shown for shaft and housing diameters. Tolerance of outer ring Width is +0 to -0.20 mm.
Product Overview
